精密壓力表 YB150A 0.4級
產品概述
精密壓力表YB-150A 0.4級是一種高精度測量儀表，主要用于工業場景中壓力參數的精密測量與校驗工作。該儀表采用優質彈簧管作為核心測量元件，通過精密的齒輪傳動機構將壓力信號轉換為直觀的指針指示。表盤下方設有鏡面環設計，可有效減少視差，使讀數更加清晰準確。儀表外殼采用堅固材質制成，具有良好的密封性能，能夠適應多種工業環境的使用需求。123
技術特點
YB-150A型精密壓力表具備0.4級的測量精度，適用于測量對銅合金及合金結構鋼無腐蝕性的氣體或液體介質壓力。其測量范圍覆蓋-0.1-0MPa至0-60MPa多種量程可選，使用環境溫度為5-40℃，相對濕度不超過80%。當環境溫度偏離20±3℃時，需考慮溫度附加誤差的影響。儀表采用徑向螺紋連接方式，公稱直徑150mm，整體重量約1kg，便于安裝和使用。359
應用領域
該型號壓力表廣泛應用于石油化工、制藥食品、紡織造紙等工業領域，既可作為校驗普通壓力表的標準器具，也可用于工藝現場對非結晶、非凝固介質的精密壓力測量。其穩定的性能和可靠的測量結果，使其成為工業生產過程控制和實驗室壓力檢測的理想選擇。儀表的結構設計和材料選用充分考慮了工業環境的適用性，能夠滿足不同場景的測量需求。21322
Product Overview
The YB-150A precision pressure gauge (0.4 grade) is a high-accuracy measuring instrument designed for pressure parameter verification and precise measurement in industrial applications. Featuring a premium spring tube as the core sensing element, it converts pressure signals into clear pointer indications through precision gear transmission mechanism. The mirrored ring beneath the dial effectively minimizes parallax, ensuring more accurate readings. Its robust housing provides excellent sealing performance, making it suitable for various industrial environments.1710
Technical Features
This 0.4-grade precision pressure gauge is suitable for measuring non-corrosive gas or liquid pressure on copper alloys and alloy structural steel. With measurement ranges from -0.1-0MPa to 0-60MPa, it operates within ambient temperatures of 5-40℃ and relative humidity below 80%. When ambient temperature deviates from 20±3℃, temperature compensation should be considered. The gauge adopts radial threaded connection with 150mm nominal diameter, weighing approximately 1kg for easy installation and operation.3816
Applications
Widely used in petroleum, chemical, pharmaceutical and food processing industries, this gauge serves both as a standard device for verifying ordinary pressure gauges and for on-site precise measurement of non-crystallizing media. Its stable performance and reliable measurements make it an ideal choice for industrial process control and laboratory pressure testing. The structural design and material selection ensure excellent adaptability to various industrial measurement requirements.21419
