產品名稱：YB150A 00.1MPa 數顯式精密壓力測量儀表
Product Name: YB150A 00.1MPa Digital Precision Pressure Gauge
產品概述
YB150A系列數顯壓力表是一款專為工業領域設計的精密測量儀器，采用數字化顯示技術實現壓力參數的直觀讀取。本產品適用于各類氣體、液體介質的靜態壓力測量，通過優化傳感器結構和信號處理算法，為用戶提供穩定可靠的壓力監測解決方案。
核心特點
-
精密測量性能
搭載高靈敏度壓力傳感器與溫度補償系統，在0.1MPa至100MPa量程范圍內保持±0.5%FS的測量精度，滿足實驗室級測量需求。顯示分辨率可達0.001MPa，有效捕捉微小壓力變化。
-
智能化功能配置
• 4位LCD顯示屏支持壓力值實時顯示
• 單位切換功能（MPa/psi/bar）
• 峰值保持與數據鎖定功能
• 低功耗模式延長電池使用壽命
-
工業級防護設計
表體采用304不銹鋼與防震結構設計，防護等級達到IP65，可適應-20℃至70℃工作環境。配備耐腐蝕隔離膜片，有效應對油污、水汽等復雜介質環境。
-
人機交互優化
• 硅膠按鍵實現參數快速設置
• 背光顯示支持暗環境讀數
• 可調式安裝支架適配不同觀測角度
典型應用
• 液壓系統壓力監測
• 氣動裝置壓力校準
• 工業管道壓力診斷
• 精密儀器配套檢測
• 科研實驗數據采集
技術參數
測量介質：兼容性氣體/液體
顯示精度：±0.5%滿量程
工作溫度：-20~70℃
供電方式：DC3V紐扣電池（標準配置）
接口規格：G1/2"陽螺紋（可定制）
產品優勢
該儀表通過模塊化結構設計實現了測量性能與使用便利性的平衡，緊湊型外觀（Φ60mm表盤）方便現場安裝。全量程線性校準技術確保長期使用穩定性，特別適用于需要連續監測的工業場景。
（注：本產品可根據需求定制量程范圍與機械接口規格）
English Version:
Product Introduction
The YB150A series digital pressure gauge delivers precise pressure monitoring through advanced digital display technology. Engineered for industrial applications, this instrument provides reliable measurement for both gaseous and liquid media under static pressure conditions.
Key Features
-
High-Precision Measurement
Equipped with sensitive pressure sensor and temperature compensation system, achieves ±0.5% FS accuracy across 0.1MPa to 100MPa range. 0.001MPa resolution ensures detection of minute pressure variations.
-
Intelligent Functions
• 4-digit LCD display with real-time monitoring
• Switchable measurement units (MPa/psi/bar)
• Peak hold and data freeze functions
• Power-saving mode extends battery life
-
Rugged Construction
IP65-rated 304 stainless steel housing withstands industrial environments. Integrated shock-resistant design maintains performance from -20℃ to 70℃. Corrosion-resistant diaphragm ensures durability.
-
User-Centric Design
• Ergonomic silicone operation buttons
• Adjustable-angle mounting bracket
• Backlit display for low-light conditions
Typical Applications
• Hydraulic system monitoring
• Pneumatic equipment calibration
• Industrial pipeline diagnostics
• Laboratory research applications
• Process control systems
Technical Specifications
Measurement Media: Compatible gases/liquids
Accuracy: ±0.5% FS
Operating Temperature: -20~70℃
Power Supply: Standard CR2032 battery
Connection: G1/2" male thread (customizable)
Product Highlights
The compact design (Φ60mm dial) combines measurement stability with installation flexibility. Linear calibration technology guarantees long-term reliability, making it ideal for continuous monitoring in demanding industrial environments.
(Note: Customizable pressure ranges and mechanical interfaces available upon request)
